AWS Rest API Gateway - URL Shortener
AWS offers a managed service for API Gateway that comes in three types: http, rest and websocket. A common pattern of usage of these services is in combination with serverless services like Lambdas, DynamoDB tables, S3, etc. But the rest version of these service is more capable than most people think and using it just as a proxy to a lambda containing all the logic of execution is a waste of potential (and money).
For simple use cases where no logic will run in the API Gateway, the http type is better suited (and even using lambdas new http endpoint feature directly), but if you find yourself in a situation where logic to implement is not too complex, you should know some endpoints logic could be implemented directly with this service.
What can be done with an AWS Rest API Gateway?
Let’s first take a look at some definitions the service has, the interaction within the system is mainly done between a client, the service itself and a external service that will process the information (there are edge cases where the last party is not involved).
In each of the 4 steps represented with the arrows the API Gateway can execute basic mapping logic (trough the usage of the VTL templating language). This feature combined with the native integrations that this service offers with other AWS services, we can essentially create some apps without the need of a single line of code. Let’s take a closer look to each part of this flow.
Method request
The first part of the flow represents the request sent by the client to the API. Something that can look like:
GET /users?page=1 HTTP/1.1
Host: apigatewayid.amazonaws.com
Accept: application/json
These parameters (method, path, query parameters, headers, etc.) are taken by the API and can be declared to be used later. In this stage we only declare things we would like to use in later mappings.
Integration request
At this stage, we configure our API to make a request to the external service. The possible integration types are:
AWS: Integrate with other AWS services, this is the type we are using throughout this guide.AWS_PROXY: Just use the API as a proxy to a lambda, no intervention is done to the request or response.HTTP: Integrate with an external generic http server.HTTP_PROXY: Integrate with an external generic http server as a proxy, no intervention is done to the request or response.MOCK: Mock the response a server would do, useful for testing without incurring costs.
For non-proxy integration types, we will need to create the http request to be made to the external service, and we can use values we get from the original request done by the client. In proxy scenarios, the request is redirected as is to the server.
In this example, we will use AWS integration type to talk to other AWS services using custom mapping of client requests. An example request to DynamoDB would look like:
POST /GetItem HTTP/1.1
Host: arn:aws:apigateway:us-east-1:dynamodb:action
Accept: application/json
Integration response
The third part of the process is called integration response, and it represents the API gateway receiving the response from the external server. This part of the process must map different responses given by the server to responses sent to the client, represented mainly by the status code and content type received from the server and sent to the client. Status codes usually gives us information about the processing the server did and its result, and the Content-Type header have information about the format the content of the response have. For example, a response from DynamoDB could be:
HTTP/1.1 200 OK
Content-Type: application/json
Body: {"Items": []}
Method response
The last step of the process is actually returning the response to the client that started the request. Here we define which response codes, headers and (optionally) body will be sent to the client. In non-proxy scenarios, this data can be harcoded in the configuration or mapped from values obtained as part of the integration response. We can, for example, configure our API to give the following response:
HTTP/1.1 301 MOVED_PERMANENTLY
Location: https://renaiss.io/about
So, what is a URL shortener?
Essentialy a URL shortener is a service that make aliases for long URLs into shorter ones. For example, if we want to share a link like https://subdomain.example.com/path1/path2/?var1=value1&var2=value2#fragment, a shortener would allow you to create a short alias url like https://domain.com/url1 that will respond a 301 when queried and redirect to the original url.
An http server that exposes the following endpoints should be sufficient:
# Get the short URL and redirect to original URL
GET /:id
# Create new short URLs
POST /url
# List all URLs created
GET /url
Get short URL
With this in mind, if we maintain the information of the different aliases and the url they should redirect to in a database, our server should only do a mapping of a GET request to a query to the database where that info is, and in the mapping back to the client, convert the response into a 301 response with the Location header set to the URL stored in the database. The following graph reflects how the API gateway could do this while requesting the information to a DynamoDB table:
As you can see, the :id sent by the client is used create the body sent to DynamoDB; and if DynamoDB request is successful, the parameter that comes in the response body <long-url> is mapped to the Location header (the response code of this endpoint will always be 301).
Create new alias
Ok, but how do we create entries in the DynamoDB table to begin with? Well, we can create a different interaction with our API Gateway that could be used for this purpose. To follow Rest APIs rules, we can have an endpoint that accepts a POST request with the required information in the body in order to create a new entity. The integration would look like:
Our API receive a POST request with information about the url to be created (id and the real long url). It then executes the creation of this record in DynamoDB, and if everything is correct, retrieves information about the created URL back to the client.
List all aliases from the database
If we continue with this logic, we could also add a different endpoint that lists all aliases created using the same kind of integration we have been using. This time, we need to perform a scan in the DynamoDB table, and following the same structure, it could be mapped to a GET request to the /url endpoint.
Adding a frontend for user interaction
Even though our server is fully functional at this point, users must interact directly using HTTP requests with it. Let’s create a very basic web interface for this purpose (just a couple of static html+css+js files using bootstrap), and serve it with the same API we have been usign, because why not.
There are many ways of hosting a static web page in AWS, and almost all of the involves using s3 to store the files. The main difference from there on, is who acts as the HTTP server that serves the static files. In our use case, we will add some endpoints to our API Gateway that can serve those files for us.
# Get the index.html file
GET /
# Get static web files
# We want the short URL to be the one that
# uses /:id so we will add an extra path
POST /website/:file
Get index.html
The main endpoint of our API Gateway (/) will return the main html page of our frontend. It will be mapped to do a get to that file in s3, and map back the content with a 200 and the Content-Type mapped to the same header returned by the request to s3.
In this case we know that for this path we will always do the same request to s3, so we don’t need to do any integration request mapping, we just need to get the body of the s3 response and give it back to the client.
Get all frontend files
To expose an endpoint for the rest of the files used in the frontend (css and js files referenced from the main html), we will use all path with the prefix website to leave the main /:id path free for shortened urls. The main difference with the path implemented for /, in this case we don’t know beforehand which Content-Type the answer of s3 will have, it will depend on the file being requested. So we will need to map the Content-Type sent from s3 to the one sent back to the client:
OpenAPI spec
Now that we understand what is the role of the API Gateway, let’s see how we can configure it. Of course the first option would be to go to the AWS console and create/configure the API Gateway there. But, if we want to use IaC to configure the resources, there are two options. Assuming we use Terraform, we can use the resources defined in the AWS provider to create the different path with their method/integration configurations (api_gateway_resource, api_gateway_method, api_gateway_method_response, etc.) or we can use the OpenAPI definition feature supported by the service.
OpenAPI specifications is a standard way of defining APIs with great adoption and widely used to document them. Many tools and utilities are built around this specification. What AWS Api Gateway allows you to create an API by providing the OpenAPI definition of the required configuration. Given this kind of server have some AWS specific integrations that are not part of this standard, an extension of the standard is provided by AWS to include custom integrations into this specification.
Let’s break the different parts we need to implement into how they look in OpenAPI standards (using the extension provided by AWS):
paths:
# index.html endpoint
"/":
get:
# Define integration with s3 using AWS extension
x-amazon-apigateway-integration:
type: aws
passthroughBehavior: when_no_templates
uri: arn:aws:apigateway:us-east-1:s3:path/bucket-name/index.html
# Method expected by s3 api
httpMethod: GET
# Credentials used by API Gateway to query s3 object
credentials: <iam-role>
# Declare Content-Type mapping
# In this case we could override the var cause we know the file type will be html
responses:
default:
statusCode: "200"
responseParameters:
"method.response.header.Content-Type": "integration.response.header.Content-Type"
# Map 200 response and use Content-Type returned by s3
responses:
default:
"200":
headers: { "Content-Type" = { schema = { type = "string" } } }
# Website endpoint
"/web/{object}":
get:
# Define integration with s3 using AWS extension
x-amazon-apigateway-integration:
type: aws
passthroughBehavior: when_no_templates
uri: arn:aws:apigateway:us-east-1:s3:path/bucket-name/{object}
# Method expected by s3 api
httpMethod: GET
# Credentials used by API Gateway to query s3 object
credentials: <iam-role>
# Map input parameter to object defined in the integration path
requestParameters: { "integration.request.path.object" = "method.request.path.object" }
parameters:
- name: object
in: path
required: true
schema: { type: "string" }
# Map 200 response and use Content-Type returned by s3
responses:
default:
"200":
headers: { "Content-Type" = { schema = { type = "string" } } }
# Endpoints to manage URLs in DynamoDB
# This actually accepts two methods: GET to list and POST to create
"/url":
get:
# Define integration with dynamodb using AWS extension
x-amazon-apigateway-integration:
type: aws
passthroughBehavior: when_no_templates
uri: arn:aws:apigateway:us-east-1:dynamodb:action/Scan
# Method expected by dynamodb api
httpMethod: POST
# Credentials used by API Gateway to query dynamodb table
credentials: <iam-role>
# Create body to send in the request to dynamodb
requestTemplates: { "application/json": { TableName: "<table-name>" } }
# Map responses received from dynamodb
responses:
"200":
statusCode: "200"
# Parse response from dynamodb
# https://docs.aws.amazon.com/amazondynamodb/latest/APIReference/API_Scan.html#API_Scan_ResponseSyntax
responseTemplates: { "application/json" = "$input.path('$').Items" }
# Mappings of the method response must be declared
responses:
"200":
description: 200 response
post:
# Define integration with dynamodb using AWS extension
x-amazon-apigateway-integration:
type: aws
passthroughBehavior: when_no_templates
uri: arn:aws:apigateway:us-east-1:dynamodb:action/UpdateItem
# Method expected by dynamodb api
httpMethod: POST
# Credentials used by API Gateway to query dynamodb table
credentials: <iam-role>
# Create body to send in the request to dynamodb
requestTemplates:
"application/json":
TableName: <table-name>
Key:
id: { "S": "$input.json('$.id').replaceAll('\"', '')" }
UpdateExpression: "SET #u = :u"
ExpressionAttributeNames: { "#u": "url" }
ExpressionAttributeValues: { ":u": { "S": "$input.json('$.url').replaceAll('\"', '')" }}
# Map dynamodb response
responseTemplates:
"application/json": |
#set($inputRoot = $input.path('$'))
{
"id": "$inputRoot.Attributes.id.S",
"url": "$inputRoot.Attributes.id.S",
}
# Mappings of the method response must be declared
responses:
"200":
description: 200 response
# Endpoint to use shortened URLs
"/{id}":
get:
# Define integration with dynamodb using AWS extension
x-amazon-apigateway-integration:
type: aws
passthroughBehavior: when_no_templates
uri: arn:aws:apigateway:us-east-1:dynamodb:action/GetItem
# Method expected by dynamodb api
httpMethod: POST
# Credentials used by API Gateway to query dynamodb table
credentials: <iam-role>
# Create body to send in the request to dynamodb
requestTemplates:
"application/json":
TableName: <table-name>
Key:
id: { "S": "$util.escapeJavaScript($input.params().path.id)" }
# Map the response from dynamodb to the 301 response we need
responses:
"200":
statusCode: "301"
responseTemplates:
"application/json": |
#set($inputRoot = $input.path('$'))
#if ($inputRoot.toString().contains("Item"))
#set($context.responseOverride.header.Location = $inputRoot.Item.url.S)
#end
Yes, I know, this seems more complex than necessary, but remember we are replacing all the code that would be running in a lambda serving static files and interacting with dynamodb.
Terraform code
The article was focused in the API Gateway configuration, but in a real scenario we will need to create and configure other resources as part of the solution, like the DynamoDB table, the S3 bucket and some IAM resources. For a complete functional example of this concept you can check a terraform module where I implement everything. The source code can be found here, and you can use it like:
module "url-shortener" {
source = "MaximilianoAguirre/url-shortener/aws"
version = "1.0.0"
}
Conclusions
The Rest version of the AWS API Gateway is very powerful and it could even allow for a simple app to be embedded in its logic. Of course this is not optimal in many scenarios, and a proxy integration with a lambda will be easier to develop and maintain in most scenarios, but some use cases are valid for simple mappings and could be still integrated in “proxy” scenarios.
Other integrations that can be useful (and you can explore) are:
- Integrating with an AWS Step Function for a more complex flow of logic.
- Execute a job with AWS Batch and use long polling to wait until a successful execution.
